Technical parameters

1. Voltage: AC100-240 - v, 50/60 hz
2. The light bulb: Philips 330 w 15 r
3. The optical device: three slices of lenticular lens group, zoom 0 °, 5 °.
Electronic focusing
4. The channel mode: 20 international standard DMX512 channel
5. Horizontal: 540 ° 16 bit (scan)
Vertical scanning: 280 ° 16 bit (scan)
6. Color wheel: 9 color + white light, with two-way rotary rainbow effect
Design of pattern plate: 17 + white light, with the function of pattern jitter and arbitrary orientation
7. Stroboscopic: double pole stroboscopic frequency up to 13 times per second, and random stroboscopic and optional
Pulse stroboscopic
8. The dimming: 0% 100% linear dimming
9. Atomization: 0% 100% linear atomization
10. Panel displays, LCD liquid crystal display (LCD)
11. The stroboscopic: 0-13 times/SEC. With random stroboscopic
Rotate: 12. Prism and prism lens, can be two-way rotation. With 16 prism macro effect
13. Soft light effect: adjustable light flare Angle
14. The aperture: 5% to 100%, with an aperture effect
15. Focus: linear electronic focusing
16. The dimming: 0-100% linear adjustment, project the light range: X to 540 degrees, Y to 270 degrees
17. Can automatically correct positioning, beam Angle is 5 degrees to 27 degrees
18. Stroboscopic: double chip stroboscopic (0.5-9 times/SEC)
19. The number of motor: a total of 16 super mute motor, two three-phase motor, 16 bit driver
20. Other functions: remote control lamp switch function, display lamps and lanterns, lamp use time
21. Appearance: + high temperature resistant plastic moulding alloy material
22. Protection grade: IP20, net weight: 18.2 KG
