BM019-330 w - light beam pattern
Electric voltage: 100 v ~ 100 v / 50 ~ 60 hz
Town flow: electronic ballast
Light bubble: OSRAM SIRIUS HRI 330 w series
Town flow: electronic ballast
Light bubble: OSRAM SIRIUS HRI 330 w series
Parameter
Size
Detail
Effect light
Projection
Video
Application
Technical parameters:
Electric voltage: 100 v ~ 100 v / 50 ~ 60 hz
Town flow: electronic ballast
Light bubble: OSRAM SIRIUS HRI 330 w series
Color temperature: 7500 k
Lamp life: 1500 hours
Yan color: 14 kinds of color + white light
Figure case: 8 + 4 aperture rotation pattern
Edge mirror: can two two-way rotating prism plate, the beam Angle is free to zoom
Mirror: high precision more groups of agglutination optical lens
Soft light effect: adjustable light Angle
Light beam: multistage beam Angle change effect
Focus: linear focusing
Dimming: 0-100% linear adjustment
Cast light range: X to 540 degrees, Y to 239 degrees, can automatically correct location
Scanning speed: X to 3.0 seconds / 540 degrees, Y to 2.0 SEC / 250 degrees
Beam Angle: parallel beam Angle of 0-2.3 ° atomizing light Angle 8 °
Stroboscopic: dual-band structure, adjustable 0.5-14 times per second
Motor number: 14 super mute motor, of which two three-phase motor, 16 bit driver
Control mode: international standard DMX512
The address code: internal long life battery charging automatically, set the address code does not need to connect power of lamps and lanterns
Transport: options DMX512 wireless receiving module
Number of channels: 16 control channel, the double channel receiving pattern design
Other features: remote control switch bulb, automatic fan speed control, lamps and lanterns is closed automatically reduce the 60 w power bulb light
Outside view: high temperature resistant plastic shell, high strength alloy cold pressing molding core material
Protection grade: IP20
Lamps and lanterns of size: 380 x367x522
Net weight: 19 kg
Lumen ＆#118alue parameters: F330:20 m / 186700 lux 40 m / 48175 lux 60 m / 20855 lux
Suitable places: wedding activities, outdoor concerts, DISCO, performing arts, nightclubs, TV studio, the opera house, etc.
Electric voltage: 100 v ~ 100 v / 50 ~ 60 hz
Town flow: electronic ballast
Light bubble: OSRAM SIRIUS HRI 330 w series
Color temperature: 7500 k
Lamp life: 1500 hours
Yan color: 14 kinds of color + white light
Figure case: 8 + 4 aperture rotation pattern
Edge mirror: can two two-way rotating prism plate, the beam Angle is free to zoom
Mirror: high precision more groups of agglutination optical lens
Soft light effect: adjustable light Angle
Light beam: multistage beam Angle change effect
Focus: linear focusing
Dimming: 0-100% linear adjustment
Cast light range: X to 540 degrees, Y to 239 degrees, can automatically correct location
Scanning speed: X to 3.0 seconds / 540 degrees, Y to 2.0 SEC / 250 degrees
Beam Angle: parallel beam Angle of 0-2.3 ° atomizing light Angle 8 °
Stroboscopic: dual-band structure, adjustable 0.5-14 times per second
Motor number: 14 super mute motor, of which two three-phase motor, 16 bit driver
Control mode: international standard DMX512
The address code: internal long life battery charging automatically, set the address code does not need to connect power of lamps and lanterns
Transport: options DMX512 wireless receiving module
Number of channels: 16 control channel, the double channel receiving pattern design
Other features: remote control switch bulb, automatic fan speed control, lamps and lanterns is closed automatically reduce the 60 w power bulb light
Outside view: high temperature resistant plastic shell, high strength alloy cold pressing molding core material
Protection grade: IP20
Lamps and lanterns of size: 380 x367x522
Net weight: 19 kg
Lumen ＆#118alue parameters: F330:20 m / 186700 lux 40 m / 48175 lux 60 m / 20855 lux
Suitable places: wedding activities, outdoor concerts, DISCO, performing arts, nightclubs, TV studio, the opera house, etc.
