Technical parameters
Working voltage: 220 v, 50 hz / 60 hz
Bulb: HMI 575 w
Power: 800 w
Channel number: 16 ch / 22 ch
The light body size: L515 * H795 W445 mm
33 Kg net weight:
Control signal: DMX 512
Pattern plate: fixed pattern plate of 5 + white light
Pattern plate rotating: 5 design + white light
Color wheel: 2 + atomization + + white light cool color, 7 color + white light
Prism plate: three prism
Aperture size shrinkage, adjustable function (the light beam can be adjusted according to the requirements of field programming size)
, 7 kinds of main colour + 5 kinds of mixed color, also can make the rainbow effect at high speed.
Mechanical linear dimming, 0-100% (can control the whole effect of shading to full medallion)
1-10 times per second, ultra-high speed stroboscopic effect
Level 450 degrees, 270 degrees vertical scanning range, movements smooth, fluent, accurate positioning
Horizontal and vertical motion position can be adjusted accurately position, speed is adjustable
Horizontal, vertical adopts high precision micro step motor drive
· effect when cutting wheel rotation and position of moving light function (preparation of fixed point for a special effects)
5 fabulous fixed pattern (5 + white light fixed design)
· 4 rotating design (can be customized according to customer requirements, including inside the glass design)
Can adjust freely and reverse, speed, rotating pattern
Electronic autofocus, pattern distance are resolution can be adjusted
Prism, prism is, the free rotation function
Three convection fan cooling, internal to optimize the design of the wind road, good heat dissipation fully
Built-in overheating protection, trigger the high pressure protection
To accept international standard DMX512 digital signal
PFC power factor compensation
, in line with the various safety standards, IP20 protection level, the power cord CE20/22 standard
