Technical parameters:
The input voltage: AC100-240 - v, 50/60 hz
Rated power: 180 w
Light source: 2 r OSRAM 120 w
Color temperature: 6800 k
The light beam Angle: 2-3.2 °
Illumination light center: 10 m, more than 200000 lux,
20 m illumination light spot diameter of 480 mm, more than 480 lux
Dimension: 380 * 380 * 380 mm (length x width x height)
Carton size: 440 * 430 * 430 mm (length x width x height)
Net weight: 12.5 Kg
Total weight: 14.5 Kg
Performance characteristics:
Scanning: X 540 ° / 2.5 S, Y 270 ° / 1.5 S, precise positioning scanning,
Color plate: 13 color slice of a white light, double rainbow effect, speed adjustable, arbitrary positioning function
Pattern plate: 14 fixed pattern pieces of a white light, one-way flow, speed adjustable, arbitrary positioning function
Prism prism plate: eight sides rotating prism, forward and reverse rotation, speed is adjustable
The linear dimming: 0-100% dimmer
Focus: linear adjustment, from near to far
Stroboscopic: double chip stroboscopic 1-12 times/S, synchronous, asynchronous, random frequency flash mode, speed is adjustable
Installation site: 2 1/4 English lock
Number of channels: 13 international standard DMX512 channel
