BM023-575 w - moving head light beam pattern
Voltage: AC100-120 v / 60 hz (the model)
AC 220-250 - v / 50 hz (European models)
Power: 680 watt
AC 220-250 - v / 50 hz (European models)
Power: 680 watt
Parameter
Size
Detail
Effect light
Projection
Video
Application
Technical parameters
Voltage:
AC100-120 v / 60 hz (the model)
AC 220-250 - v / 50 hz (European models)
Power: 680 watt
Power supply: (1) or der)
HILIPS HMI discharge power 575 w
Color temperature: 6500 ° K
Lamp holder: SFC10
Power life: 750 hours
Color: 7 fixed pattern plate + white light, the bidirectional transmission with rainbow effect
Design: the design and transformation pattern plate rotating + white light, the two-way rotating speed 1 glass design
Prism: 3 mask, two-way rotating speed
Focus: electronic linear focus: 18 to 32 °
Dimming: double dimmer
0-100% linear adjustment
Shake head Angle: horizontal 540 °, 270 ° vertically.
Vertical & horizontal speed is adjustable.
Vertical & horizontal rotation: 16 bit
Control: DMX512, 12 channel
Size: W47 L51 * * H56.5 mm
Weight: 32 kg
Voltage:
AC100-120 v / 60 hz (the model)
AC 220-250 - v / 50 hz (European models)
Power: 680 watt
Power supply: (1) or der)
HILIPS HMI discharge power 575 w
Color temperature: 6500 ° K
Lamp holder: SFC10
Power life: 750 hours
Color: 7 fixed pattern plate + white light, the bidirectional transmission with rainbow effect
Design: the design and transformation pattern plate rotating + white light, the two-way rotating speed 1 glass design
Prism: 3 mask, two-way rotating speed
Focus: electronic linear focus: 18 to 32 °
Dimming: double dimmer
0-100% linear adjustment
Shake head Angle: horizontal 540 °, 270 ° vertically.
Vertical & horizontal speed is adjustable.
Vertical & horizontal rotation: 16 bit
Control: DMX512, 12 channel
Size: W47 L51 * * H56.5 mm
Weight: 32 kg
