Technical parameters
Voltage: v50 AC110V - 240-60 hz
The light bulb: HMI 1200 w
Power: 1500 w
Control signal: DMX 512
Channel number: 16 ch
Packing size: 635 * 605 * 900 mm
48 kg net weight:
53 kg gross weight:

The performance characteristics of
Six main color + white light
Color temperature calibration system
Three primary colors (C.M.Y) hybrid effect, colorful color infinite color effect (adjustable)
Three primary colors (C.M.Y) switching speed adjustable (can automatically allocate different color)
0-100% mechanical linear dimming (can control the whole effect of shading to full medallion)
Independent stroboscopic, 1-10 times/SEC ultra-high speed stroboscopic effect, speed is adjustable
Adopt LCD liquid crystal display, intelligent and quick operation information in both Chinese and English interface
The level of 450 degrees, 270 degrees vertical scanning range,
Action is smooth, fluent, accurate positioning
Horizontal and vertical each driven by a micro step motor with high precision
Usually only convection fan cooling, internal to optimize the design of the wind road, good heat dissipation fully, built-in overheating protection, trigger the high pressure protection
To accept international standard DMX512 digital signal
PFC power factor compensation
To comply with all kinds of safety standards, IP20 protection level,
The power cord CE20/22 standard
