BM030-1200 w - moving head beam light B
Voltage: AC220V / 50 hz
Power: 1400 w
Insurance: 15 a.
Light source: HMI1200W/GS
Power: 1400 w
Insurance: 15 a.
Light source: HMI1200W/GS
Parameter
Size
Detail
Effect light
Projection
Video
Application
Moving head light technology parameters
Voltage: AC220V / 50 hz
Power: 1400 w
Insurance: 15 a.
Light source: HMI1200W/GS
Control signal: DMX512
Channel number: 16 ch
Carton packing size: L630 * W610 * 895 (mm)
Net weight: 49.5 KG gross weight: 56.7 KG
Function: open/GuanGuang /
Stroboscopic: double vane mechanical linear dimming, variable speed stroboscopic 1-10 times per second
Double color piece of plate, color plate 1 (7 color + white light/with rainbow effect) color disk 2 (7 color + white light)
Double pattern plate, plate 1 (figure 4 + white light/reversible variable rotation) pattern plate of 2 (4 + white light
Prism, the comet prism, eight prism, cylindrical lens effect: can amplify bidirectional variable rotation and atomization effect
Aperture adjustment: adjustable aperture size shrinkage (a light visual field demand free adjustment)
Pattern sharpness adjust: electronic automatic adjust the focus, distance resolution automatically adjust the color temperature, atomization, pattern magnification effect
Horizontal Angle rotation (X) : 540 DHS
Vertical rotation Angle (Y) : biggest 270 DHS
Horizontal and vertical rotation speed adjustable horizontal and vertical rotation position precision adjustment
Security: the whole machine is equipped with thermal protection, trigger the high pressure protection, safe and reliable
Voltage: AC220V / 50 hz
Power: 1400 w
Insurance: 15 a.
Light source: HMI1200W/GS
Control signal: DMX512
Channel number: 16 ch
Carton packing size: L630 * W610 * 895 (mm)
Net weight: 49.5 KG gross weight: 56.7 KG
Function: open/GuanGuang /
Stroboscopic: double vane mechanical linear dimming, variable speed stroboscopic 1-10 times per second
Double color piece of plate, color plate 1 (7 color + white light/with rainbow effect) color disk 2 (7 color + white light)
Double pattern plate, plate 1 (figure 4 + white light/reversible variable rotation) pattern plate of 2 (4 + white light
Prism, the comet prism, eight prism, cylindrical lens effect: can amplify bidirectional variable rotation and atomization effect
Aperture adjustment: adjustable aperture size shrinkage (a light visual field demand free adjustment)
Pattern sharpness adjust: electronic automatic adjust the focus, distance resolution automatically adjust the color temperature, atomization, pattern magnification effect
Horizontal Angle rotation (X) : 540 DHS
Vertical rotation Angle (Y) : biggest 270 DHS
Horizontal and vertical rotation speed adjustable horizontal and vertical rotation position precision adjustment
Security: the whole machine is equipped with thermal protection, trigger the high pressure protection, safe and reliable
