BM033-1500 w - moving head beam light
The inductance ballast: AC220V / 50 hz ~ 60 hz
Bulb specifications: OSRAM HTI 1200 w/D7/60
Color temperature: 6000 k, double side, the life expectancy: 750 hours
Power rating: electronic ballast, 1500 w/the inductance ballast, 1500 w
Bulb specifications: OSRAM HTI 1200 w/D7/60
Color temperature: 6000 k, double side, the life expectancy: 750 hours
Power rating: electronic ballast, 1500 w/the inductance ballast, 1500 w
Parameter
Size
Detail
Effect light
Projection
Video
Application
Technical parameters:
The inductance ballast: AC220V / 50 hz ~ 60 hz
Bulb specifications: OSRAM HTI 1200 w/D7/60
Color temperature: 6000 k, double side, the life expectancy: 750 hours
Power rating: electronic ballast, 1500 w/the inductance ballast, 1500 w
Performance characteristics:
Color system: a color wheel: six replaceable color + white light, the CTO color temperature correction, half color effect, variable speed double rainbow effect
Figure case: 2 pattern wheels: 10 replaceable piece + white light glass design, design of wheel with functions of indexes and bidirectional effect/dynamic wheel: reversible variable rotation, and other design combination can produce water marks, such as flame effect
Focus: linear focusing
Optical zoom: a 6:1 optical zoom system, zoom Angle of 10 ° ~ 60 °
The linear dimming: 0 ~ 100% dimmer
Stroboscopic/brake light: independent double-plate stroboscopic ultra-high speed stroboscopic (1-12 times/SEC)
Circle of light: 5-100% linear adjustment
Rotation Angle: the level of 540 °, 270 ° vertically (self-return correct function, has 16 bit precision rotation)
But cold: forced convection cooling, fan speed is adjustable
Control: international standard DMX 512 signal, 3 core and 5 core interface
Tong: standard mode: 18; Extension mode: 24
Show: LCD digital display, intelligent operation information in both Chinese and English interface, display lamps and lanterns and light bulbs use time
Energy saving mode: when light brake or dimming functions are in a closed, bulbs and automatic power consumption reduced by 50%
Protection grade: IP20, built-in overheating and trigger the high pressure protection
Net weight: electronic ballasts: 44 kg/inductance ballasts, 54 kg
Gross weight: electronic ballasts: 92 kg/inductance ballasts: 102 kg
The light body size: 594 * 535 * 535 (mm)
Air air box: 690 * 620 * 620 (mm)
The inductance ballast: AC220V / 50 hz ~ 60 hz
Bulb specifications: OSRAM HTI 1200 w/D7/60
Color temperature: 6000 k, double side, the life expectancy: 750 hours
Power rating: electronic ballast, 1500 w/the inductance ballast, 1500 w
Performance characteristics:
Color system: a color wheel: six replaceable color + white light, the CTO color temperature correction, half color effect, variable speed double rainbow effect
Figure case: 2 pattern wheels: 10 replaceable piece + white light glass design, design of wheel with functions of indexes and bidirectional effect/dynamic wheel: reversible variable rotation, and other design combination can produce water marks, such as flame effect
Focus: linear focusing
Optical zoom: a 6:1 optical zoom system, zoom Angle of 10 ° ~ 60 °
The linear dimming: 0 ~ 100% dimmer
Stroboscopic/brake light: independent double-plate stroboscopic ultra-high speed stroboscopic (1-12 times/SEC)
Circle of light: 5-100% linear adjustment
Rotation Angle: the level of 540 °, 270 ° vertically (self-return correct function, has 16 bit precision rotation)
But cold: forced convection cooling, fan speed is adjustable
Control: international standard DMX 512 signal, 3 core and 5 core interface
Tong: standard mode: 18; Extension mode: 24
Show: LCD digital display, intelligent operation information in both Chinese and English interface, display lamps and lanterns and light bulbs use time
Energy saving mode: when light brake or dimming functions are in a closed, bulbs and automatic power consumption reduced by 50%
Protection grade: IP20, built-in overheating and trigger the high pressure protection
Net weight: electronic ballasts: 44 kg/inductance ballasts, 54 kg
Gross weight: electronic ballasts: 92 kg/inductance ballasts: 102 kg
The light body size: 594 * 535 * 535 (mm)
Air air box: 690 * 620 * 620 (mm)
