BM034 shook his head - 1500 w - dyeing lamp
The input voltage: 220 v, 50 hz (110 v, 60 hz)
Rated power: 1500 w, 220 v / 50 hz
Light source: PHILIPS MSR 1200 sa (lamp holder GX - 22)
Working temperature: maximum temperature: 40 ℃, the maximum surface temperature: 135 ℃
Rated power: 1500 w, 220 v / 50 hz
Light source: PHILIPS MSR 1200 sa (lamp holder GX - 22)
Working temperature: maximum temperature: 40 ℃, the maximum surface temperature: 135 ℃
Parameter
Size
Detail
Effect light
Projection
Video
Application
The technical parameters of TECH PARAMETER
The input voltage: 220 v, 50 hz (110 v, 60 hz)
Rated power: 1500 w, 220 v / 50 hz
Light source: PHILIPS MSR 1200 sa (lamp holder GX - 22)
Working temperature: maximum temperature: 40 ℃, the maximum surface temperature: 135 ℃
Color plate for a replaceable filter + white light (filter diameter size: 36.3 mm, filter size: 31.5 mm)
Color plate 2:6 a replaceable filter + white light (filter diameter size: 36.3 mm, filter size: 31.5 mm)
Infinite melange: CMY green yellow 0 0-100% magenta 0-100% - 100%
Color temperature correction: CTO dot comb structure, smooth linear temperature gradient correction function: 3200 k to 7500 k
Prism: 1 effect of wheel, rotating four prism effect
Zoom: 12 ° - 44 °
Dimming: 0-100% linear adjustment
Stroboscopic: double chip stroboscopic, 1-12 times per second
Beam Angle: 12 ° - 44 ° linear adjustment
Rotation Angle: horizontal/vertical: 540/270 °, the horizontal and vertical adopts photoelectric reset system, after the misoperation accident happen, can automatically retrieve reset
Channel number: 24/28 channel
The rectifier: electromagnetic ballast (optional) electronic ballasts
Protection grade: IP20
Other features: built-in performance program, can be manually test and precision fine-tuning design color positioning, automatic fault detection and prompt, independent channel self-inspection reset, support energy saving mode, when the dimmer in a closed, or all the CMY color piece closure, lamp power consumption reduced by 50% (electronic ballast version) extend the lamp life, improve the stability of lamps and lanterns. Have bulb lights timing function, can timely understand the usage of the light bulb
Appearance: high temperature resistant engineering plastics + surface rubber paint spraying
Size: H537mm W538 L626 * *
Packing size: W630 L600 * * H1050mm
Net weight: 52 g
Gross weight: 86 kg (including air box)
The input voltage: 220 v, 50 hz (110 v, 60 hz)
Rated power: 1500 w, 220 v / 50 hz
Light source: PHILIPS MSR 1200 sa (lamp holder GX - 22)
Working temperature: maximum temperature: 40 ℃, the maximum surface temperature: 135 ℃
Color plate for a replaceable filter + white light (filter diameter size: 36.3 mm, filter size: 31.5 mm)
Color plate 2:6 a replaceable filter + white light (filter diameter size: 36.3 mm, filter size: 31.5 mm)
Infinite melange: CMY green yellow 0 0-100% magenta 0-100% - 100%
Color temperature correction: CTO dot comb structure, smooth linear temperature gradient correction function: 3200 k to 7500 k
Prism: 1 effect of wheel, rotating four prism effect
Zoom: 12 ° - 44 °
Dimming: 0-100% linear adjustment
Stroboscopic: double chip stroboscopic, 1-12 times per second
Beam Angle: 12 ° - 44 ° linear adjustment
Rotation Angle: horizontal/vertical: 540/270 °, the horizontal and vertical adopts photoelectric reset system, after the misoperation accident happen, can automatically retrieve reset
Channel number: 24/28 channel
The rectifier: electromagnetic ballast (optional) electronic ballasts
Protection grade: IP20
Other features: built-in performance program, can be manually test and precision fine-tuning design color positioning, automatic fault detection and prompt, independent channel self-inspection reset, support energy saving mode, when the dimmer in a closed, or all the CMY color piece closure, lamp power consumption reduced by 50% (electronic ballast version) extend the lamp life, improve the stability of lamps and lanterns. Have bulb lights timing function, can timely understand the usage of the light bulb
Appearance: high temperature resistant engineering plastics + surface rubber paint spraying
Size: H537mm W538 L626 * *
Packing size: W630 L600 * * H1050mm
Net weight: 52 g
Gross weight: 86 kg (including air box)
