Technical parameters:
Power supply: 100-240 - v, 50/60 hz
Bulb models: OSRAM SIRIUS HRI 280
The light source power: 280 w
DMX channels: 16/20 two channel selection pattern
Display: touch screen LCD display, reversing 180 ° display
Color plate: a color plate, color has 14 + white light
Two pattern plate, pattern plate: fixed pattern plate of 17 + white light, nine rotation pattern effect
Round effect: a rotating prism 3, atomization function
Dimming: 0-100% mechanical dimmer, support mechanical stroboscopic and adjustable speed stroboscopic effect, frequency ShanHong support functions.
Lens group of optical system, electric focus, beam Angle of 0 ~ 20 °
Using photoelectric reposition system, after the misoperation accident happen, can automatically retrieve reset
Level 540 °, 8 bit / 16 bit resolution
270 ° vertically, 8 bit / 16 bit resolution
Overheating protection

Control mode: DMX512 / master-slave/automatically
IP protection grade: IP20 electronic rectifier.
Size: 523 (length) x 337 (width) x 570 mm (high)
Net weight: 18.5 KG

Protection grade: IP24 does installation environment
Ambient temperature: 55 ℃ and 40 ℃ - +
Humidity: 10%, 90% TH
Suitable for any position
Features: small volume, light weight, can be used on any occasion. Run very fast, stroboscopic high rate; Shell aluminum or high strength heat-resistant engineering for the whole PC plastic shell, a molding; Super mute motor, running low noise, head balance performance is good! (optional three-phase motor, prism magnification)
