BM0113-15 - r - 330 - w moving head light beam pattern
Electric voltage: 100 v to 240 v / 50 to 60 hz,
Ballast, electronic ballast
Light bulbs, OSRAM SIRIUS HRI 330 w
Color temperature: 7500 k
Ballast, electronic ballast
Light bulbs, OSRAM SIRIUS HRI 330 w
Color temperature: 7500 k
Parameter
Size
Detail
Effect light
Projection
Video
Application
Electric voltage: 100 v to 240 v / 50 to 60 hz,
Ballast, electronic ballast
Light bulbs, OSRAM SIRIUS HRI 330 w
Color temperature: 7500 k
The average life expectancy: 1500 h
Number of Channels: 3 DMX Modes 21/23/34 Channels DMX
Control mode: 23 international standard DMX512 control, master-slave mode, the mode.
LCD liquid crystal display, DMX 3 or 5 core signal input
Lens: antireflection coating glass lens
Yan color: 6 colors + blank With full color or color features, also has the UV and heat insulation piece, CMY color mixture system
Fixed pattern: with a blank piece + 14 fixed pattern
Rotating pattern: contains eight rotary design and blank, design piece can free change plug
Stroboscopic: 0-13 times per second. With random stroboscopic
Prism and prism rotating: rotating three lens, can be reversible. Prism rotating, with 16 prism macro effect.
Soft light effect: soft light flare Angle can be adjusted
Circle of light: 5% to 100%, with an aperture effect
Focus: linear electronic focusing
Dimming: 0-100% linear adjustment
Project the light range: X to 540 degrees, Y to 270 degrees, can automatically correct location
Beam Angle: 5 ° to 27 °
Stroboscopic: double chip stroboscopic (0.5-9 times/SEC)
Number of motors: a total of 16 super mute motor, two three-phase motor, 16 bit driver
Other features: remote control lamp switch function, use time display lamps, bulbs,
Outside view: high temperature resistant plastic + moulded alloy material
Protection grade: IP20
23 KGS net weight:
Ballast, electronic ballast
Light bulbs, OSRAM SIRIUS HRI 330 w
Color temperature: 7500 k
The average life expectancy: 1500 h
Number of Channels: 3 DMX Modes 21/23/34 Channels DMX
Control mode: 23 international standard DMX512 control, master-slave mode, the mode.
LCD liquid crystal display, DMX 3 or 5 core signal input
Lens: antireflection coating glass lens
Yan color: 6 colors + blank With full color or color features, also has the UV and heat insulation piece, CMY color mixture system
Fixed pattern: with a blank piece + 14 fixed pattern
Rotating pattern: contains eight rotary design and blank, design piece can free change plug
Stroboscopic: 0-13 times per second. With random stroboscopic
Prism and prism rotating: rotating three lens, can be reversible. Prism rotating, with 16 prism macro effect.
Soft light effect: soft light flare Angle can be adjusted
Circle of light: 5% to 100%, with an aperture effect
Focus: linear electronic focusing
Dimming: 0-100% linear adjustment
Project the light range: X to 540 degrees, Y to 270 degrees, can automatically correct location
Beam Angle: 5 ° to 27 °
Stroboscopic: double chip stroboscopic (0.5-9 times/SEC)
Number of motors: a total of 16 super mute motor, two three-phase motor, 16 bit driver
Other features: remote control lamp switch function, use time display lamps, bulbs,
Outside view: high temperature resistant plastic + moulded alloy material
Protection grade: IP20
23 KGS net weight:
