BM0322-1200 w - shook his head lamp design
Voltage: 90 v to 264 v / 47 hz - 63 hz (on-demand customized)
Ballast: magnetic induction or electronics
Bulb: PHILIPS: MSI (color temperature) : 1200 5600 k
MSI 1200 w/S (color temperature) : 6000 k
Ballast: magnetic induction or electronics
Bulb: PHILIPS: MSI (color temperature) : 1200 5600 k
MSI 1200 w/S (color temperature) : 6000 k
Parameter
Size
Detail
Effect light
Projection
Video
Application
Technical parameters
Voltage: 90 v to 264 v / 47 hz - 63 hz (on-demand customized)
Ballast: magnetic induction or electronics
Bulb: PHILIPS: MSI (color temperature) : 1200 5600 k
MSI 1200 w/S (color temperature) : 6000 k
OSRAM: HMI1200W/S XS (color temperature) : 6000 k
HMI1200W/GS (color temperature) : 6000 k
The total power consumption: 1400 w
Signal: DMX 512
Channel: 16-24 ch
Motor number: 16
Aviation carton size: 600 * 460 * 935 mm
: net weight 50 kg gross weight: 75 kg
The performance characteristics of
Control table can be individually controlled motor self-checking, automatic reset
DMX controller can control the lamp body address function display stand, stand, and DMX signal light is lit, closing
Aperture size shrinkage adjustable function (the light beam can be adjusted according to the requirements of field programming size)
Eight kinds of main colour + 8 types of mixed color, at the same time as a high-speed one-way rolling effect
0-100% mechanical linear dimming (can control the whole effect of shading to full medallion)
1-7 times/SEC ultra-high speed stroboscopic effect
Level 540 degrees, 250 degrees vertical scanning range, movements smooth, fluent, accurate positioning
Horizontal and vertical direction can be adjusted accurately position and movement speed
Each channel has cut light function (can be used in the preparation of fixed point for a special effects)
Eight exquisite design, including 2 piece of glass design (can be customized according to customer requirements)
Can be positive and negative rotation design, speed regulating freedom
Rotating pattern Angle can be adjusted separately
Using the infinite zoom zoom function 13 degrees to 32 degrees, can be arbitrary regulation
Prism (renewable) is, the free rotation function
Six fan cooling, cold air from the lamp head part into the bulb fever warehouse, keep the light in the head of the parts in low temperature environment can prolong the service life, and can make the light bulbs emit heat can be directly discharge in a timely manner, to ensure the whole lamp body always stay at the design temperature range, the built-in overheating protection, good heat dissipation fully
PFC power factor compensation, even in the voltage fluctuation (plus or minus 10 v) environment can also be used
To comply with all kinds of safety standards, IP20 protection level, the power cord CE20/22 standard
Fast installation is simple, using a set of a quarter of a spin lock, solid security (on the basis of actual configuration)
Voltage: 90 v to 264 v / 47 hz - 63 hz (on-demand customized)
Ballast: magnetic induction or electronics
Bulb: PHILIPS: MSI (color temperature) : 1200 5600 k
MSI 1200 w/S (color temperature) : 6000 k
OSRAM: HMI1200W/S XS (color temperature) : 6000 k
HMI1200W/GS (color temperature) : 6000 k
The total power consumption: 1400 w
Signal: DMX 512
Channel: 16-24 ch
Motor number: 16
Aviation carton size: 600 * 460 * 935 mm
: net weight 50 kg gross weight: 75 kg
The performance characteristics of
Control table can be individually controlled motor self-checking, automatic reset
DMX controller can control the lamp body address function display stand, stand, and DMX signal light is lit, closing
Aperture size shrinkage adjustable function (the light beam can be adjusted according to the requirements of field programming size)
Eight kinds of main colour + 8 types of mixed color, at the same time as a high-speed one-way rolling effect
0-100% mechanical linear dimming (can control the whole effect of shading to full medallion)
1-7 times/SEC ultra-high speed stroboscopic effect
Level 540 degrees, 250 degrees vertical scanning range, movements smooth, fluent, accurate positioning
Horizontal and vertical direction can be adjusted accurately position and movement speed
Each channel has cut light function (can be used in the preparation of fixed point for a special effects)
Eight exquisite design, including 2 piece of glass design (can be customized according to customer requirements)
Can be positive and negative rotation design, speed regulating freedom
Rotating pattern Angle can be adjusted separately
Using the infinite zoom zoom function 13 degrees to 32 degrees, can be arbitrary regulation
Prism (renewable) is, the free rotation function
Six fan cooling, cold air from the lamp head part into the bulb fever warehouse, keep the light in the head of the parts in low temperature environment can prolong the service life, and can make the light bulbs emit heat can be directly discharge in a timely manner, to ensure the whole lamp body always stay at the design temperature range, the built-in overheating protection, good heat dissipation fully
PFC power factor compensation, even in the voltage fluctuation (plus or minus 10 v) environment can also be used
To comply with all kinds of safety standards, IP20 protection level, the power cord CE20/22 standard
Fast installation is simple, using a set of a quarter of a spin lock, solid security (on the basis of actual configuration)
